Autel MaxiSys MS908S PRO II
As one of the most advanced scan tools in the Autel MaxiSys family, Autel MaxiSys MS908S Pro II scan tool is equipped with a powerful Cortex A7+A15 six-core processor and 64GB internal memory for better performance. It operates on Android OS, which is not only fast but allows the user to multitask and manage many applications at the same time.
With the MaxiFlash Elite VCI(J-2534 programmer), the Autel ms908spro II is capable of performing ECU programming on Benz and BWM; a great scan tool for professional technicians, mechanics, and large Auto repair shops.
Top 6 Reasons to Buy Autel Maxisys 908SPro II
- No IP Blocking Problem - Global Version, You can use it everywhere.
- Wi-Fi Technology - The VCI connects wirelessly to the main unit with Long-Range Class 1 Bluetooth
- Easy to use - Simple and intuitive software navigation
- Worldwide Coverage - MS908SPRO has extensive vehicle coverage for more than 80 US, Asian and European vehicle makes, including supercars.
- ECU Programming - MS908SPRO II is able to perform ECU programming on BMW & Benz vehicles
- Free Software Update - Diagmart provides one-year free software update online for MS908SPRO
Autel CAN FD Adapter
Autel CAN FD Adapter is designed to support diagnosis of vehicle models with CAN FD protocol, including the MY2020 GM models.
This CAN FD Adapter is compact, portable, and easy to use.
Step1: Connect the main cable’s female adapter to the vehicle Data Link Connector(DLC) on the VCI unit and tighten the captive(thumb) screws.
Step 2: Connect the CAN FD Adapter’s 16-PIN female connector to the main cable’s male adapter.
Step 3: Connect the attached CAN FD adapter to the vehicle’s DLC which is generally located under the vehicle dashboard.
AUTEL MS908SPRO II ADVANTAGES:
31+ Advanced Maintenance Services
Your car is almost like a big investment in your life. In order to prevent your investment from dropping significantly, scheduled car maintenance is necessary. However, it does not mean that you have to take your car to a dealership for all the car maintenance.
Autel MS908S Pro II diagnostic scanner can perform various useful time and money-saving car maintenance services like Oil Reset, EPB reset, DPF Regen, ABS Bleed, SAS, Battery Registration, key fob programming, Injector Coding, Power Balance(to test injectors), Crankshaft Position Variation Learn, EGR Relearn, window, door and roof control, throttle, and etc. It can meet the needs of basic and common car maintenance, saving you time and money, also keeping you safe.
- Oil Reset Service: It allows you to perform a reset for a new calculation of the Engine Oil Life system once changed the oil.
- EPB: The service is important in the maintenance of electronic braking system's safety and efficiency.
- BMS: The service allows the scan tool to evaluate the battery charge state, monitor the close-circuit current, register the battery replacement, and activate the rest state of the vehicle.
- DPF: The service specially works for the Diesel Particulate Filter system with DPF regeneration, DPF component replacement teach-in and DPF teach-in after replacing the engine control unit.
- SAS: The service helps clear the fault steering angle sensor memories and plays an important role in the steering angle sensor calibration.
- TPMS: The service makes sense in displaying sensor IDs from the vehicle's ECU, inputting TPMS sensor replacement IDs and testing sensors.
- ABS Bleeding: ABS brake bleeding to get a firm brake pad after air exhaustion.
Seats, Odometer, Injector, CHG tire size, TEC Learn, Suspension, Throttle, WIN OR ROOF, Lang Change, Headlamp.
OE Level All Systems Diagnostics
The functionality of each of the available systems is critical for any car. Before they end up failing on you, using a diagnostic scan tool will ultimately let you know if the vehicle is safe to drive or not.
As a professional auto diagnostic tool, MS908S Pro II can access all available vehicle modules including but not limited to ECM, PCM, EPS, PDM, BCM, TPM, SCCM, RADIO and etc to retrieve diagnostic fault codes and view live data in graph and text, to pinpoint which cylinder has a misfire, check transmission temperature, oil temperature & pressure, camshaft position sensor status and etc.
ECU Coding & Programming
Autel MS908S Pro II comes with SAE J2534 Pass-Thru (J2534 Programmer) to replace the existing software & firmware and program new ECUs for BMW & Benz vehicles to fix software-controlled drivability issues and emission issues.
ECU Coding function allows you to update the computer software on the vehicle to the latest version, recode adaptive data for certain components after making repairs or replacements to improve driving performance, fuel efficiency and reduce power loss. Available coding operations vary by the test vehicle, and only the available operations are displayed in the menu.
Active Tests/Bi-Directional Control
Autel MS908S Pro II auto diagnostic tablet comes with bi-directional control capability for specific car systems, which allows you to locate an issue without having to rip everything apart. Right from your scan tool, you can control the parking lamps, tail lamps, headlamps, front wiper, rear wiper, parking lamps, license plate lamps, A/C compressors, daytime running lights, cooling fan, door switch, and windows, and oil pressure warning lamps.
This way, you won’t have to drive your car or use in-car controls to recreate the problems it had. You can actuate solenoids and actuators with any of the scanners and send specific instructions to check the working status of specific components or systems.
Maxisys MS908SPRO II Coverage:
Autel MaxiSys MS908S Pro automotive scanner tablet comes with unmatched vehicle coverage of more than 80 American, Asian and European vehicle makes and models.
- For Asian: Acura, Daihatsu, Hyundai, Infinit, Kiat, Mazda, Nissan, Scion, Subaru, Toyota, Manhindra, Proton, Daewoo, Honda, HyundaiCV, Isuzu, Lexus, Mitsubishi, Samsung, Ssang Yong, Suzuki, Fuso, Perodua, Tata, ect.
- For European: VW, Abarth, Aston Martin, MINI, Sprinter, SKODA, Citroen, Fiat, Lancia, Maserati, Opel, Porsche, SAAB, Vauxhall, Seat, Bugatti, Audi, BMW, Alfa, Benz, Maybach, Ferrari, Jaguar, Land Rover, Peugeot, Renault, Smart, Volvo, Lamborghini, Bentley, Rolls-Royce, VW CV, Dacia, LT3, ect.
- For the USA: Chrysler, Dodge, Ford, GM, JEEP, ect.
Key Fob Programming Capability
The Key Fob Programming is designed for Asian vehicles that have low-grade anti-theft systems and NOT intended for AUDI, Benz, BMW, VW which have advanced IMMO systems.
NOTE: Key Programming function is NOT universally compatible. Please always send us VIN number to check compatibility before purchase.
However, for BMW, Benz, VW and other high immo grade vehicles, we recommend professional IMMO & Key Programming tools like Autel IM508, Autel IM508S, Autel IM608 II.
Autel MaxiSys MS908S Pro II Add-On Functions:
To better serve the users, the diagnostic tool is equipped with a rich array of features and functions in addition to the Diagnostic and Service functions, including Remote Desk, MaxiFix, Shop Manager, Digital Inspection, MaxiScope, etc.
- Remote Desk: With the simple, fast and secure remote control interface, you can receive ad-hoc remote support from Autel' s support center, by allowing them to control your MaxiCOM tablet on their PC via the TeamViewer software.
- MaxiFix: This is an additional feature in the cloud that enables users to network and access a database of procedures, repair and diagnostic tools. You are able to interact with fellow technicians and share knowledge via MaxiFix.
- Digital Inspection & MaxiScope: The diagnostic scan tool can also be used in conjunction with the automotive oscilloscope Autel MP408 to perform electrical and electronic circuit testing and monitor signal activity, and it also supports performing a close vehicle inspection with the Autel digital inspection camera MV105/MV108
